Description
Outdoor locations such as stadiums, arenas can have the most demanding wireless requirements due to high client density. The T750 access point (AP), based on the latest Wi-Fi 6 standard, brings in multi-gigabit Wi-Fi to support the ever raising expectation for highest quality of service from the users. T750 is IP-67 rated to withstand the rigors of outdoor deployments.
The RUCKUS T750 is our high-end dual-band, dual-concurrent Wi-Fi 6 AP that supports 8 spatial streams (4×4:4 in 5GHz, 4×4:4 in 2.4GHz). The T750, with OFDMA and MU-MIMO capabilities, efficiently manages up to 1,024 client connections with increased capacity, improved coverage and performance in ultra-high dense environments. Furthermore, the 2.5 GbE ethernet ensures that the backhaul will not be a bottleneck for full use of available Wi-Fi capacity.
The T750 addresses the increasing client demands in public venues such as airports, convention centers, plazas, malls, and other dense urban environments. It is the perfect choice for data-intensive streaming multimedia applications like 4K video transmissions, while supporting latency sensitive voice and data applications with stringent quality-of-service requirements.The T750 is also easy to manage through physical, virtual and cloud management options.
- Great Outdoor Wi-Fi – Experience high performance outdoor Wi-Fi 6 with IP-67 weather proofing and dual backhaul options with SFP and multi-gigabit 2.5 GbE ethernet port
- Connect More Devices Simultaneously – Improve device performance, by enabling more simultaneous device connections with built-in 8 spatial streams (dual-concurrent, 4×4:4 in 5GHz, 4×4:4 in 2.4GHz), MU-MIMO and OFDMA technology while enhancing non-Wi-Fi 6 client performance. Support for up to 1,024 clients
- High Density Performance – Provide exceptional end-user experience within high density public venues such as airports, amusement parks, stadiums, outdoor arenas, and other dense outdoor urban environments with the RUCKUS Ultra-High-Density Technology Suite
- Converged Access Point – Allow customers to eliminate siloed networks and unify Wi-Fi and IoT wireless technologies into one single network by using built-in Bluetooth® Low Energy and Zigbee, and also expand to any future wireless technologies through the pluggable IoT module
- Power Other Devices – Daisy chain and power other devices like an IP camera, or another AP directly from the 1 GbE PoE output port
- Multiple Management Options – Manage the T750 with on-premise physical / virtual appliances or from the cloud, and control auto-provisioning for faster deployment and seamless firmware upgrades
- Enhanced Security – Reinforce security with WPA3, the latest Wi-Fi security standard and receive enhanced protection from man-in-the-middle attacks
| Regional Availability |
Asia | Australia/New Zealand | EMEA | Latin America | North America |
| Product Type |
Outdoor access point |
| Product Brand |
RUCKUS® |
General Specifications
| Antenna Patterns, per band |
4000+ |
| Antenna Gain |
Up to 3 dBi |
| BeamFlex |
Yes |
| ChannelFly |
Yes |
| Concurrent Users |
1024 |
| Fiber Interface |
Yes |
| IoT Support |
IoT Onboard |
| Number of Radios |
Dual-Radio |
| PD-MRC |
Yes |
| PHY Rate at 2.4 GHz, maximum |
1148 Mb/s |
| PHY Rate at 5 GHz, maximum |
2400 Mb/s |
| Combined Max PHY Rate |
3548 Mb/s |
| Radio Chains and Streams |
4×4:4 |
| SmartMesh |
Yes |
| USB |
USB 2.0 |
| Venue Type |
Hospitality | Public Venue | Transportation |
| Venue Sub-Type |
Harbor Port | Outdoor Resort Spaces | Transit Stations |
| Wi-Fi Bands Supported |
2.4 GHz | 5 GHz |
| Wi-Fi Generation |
Wi-Fi 6 |
| Wi-Fi Interface Standard |
IEEE 802.11a/b/g/n/ac/ax |
Environmental Specifications
| Operating Temperature |
-40 °C to +65 °C (-40 °F to +149 °F) |
